Monsoon PTO

The Monsoon PTO Dust Controller misting system attaches to common 540 PTO drives for dust and odor suppression.
Non-clogging proprietary Gyratory Atomizing Nozzle
Portable and lightweight. Only 240lbs!
Corded remote nozzle control.
Uses standard municipal water pressure and common 3/4″ garden hose connection.

Connect with a Sales Expert

Downloads

Manual Machine Information

SPECS & COMPARISON

Spec	Monsoon PTO	Compare a Model
Type	Three Point Hitch
Debris Type	Crop, Dust/Odor, Insect
Acreage	1 to 3, 10+, 4 to 6, 7 to 9
Input Power	Direct Drive Gearbox - 20 HP at PTO recommended
Start / Stop Control	Use Only at 540 RPM PTO Shaft Speed Max
Throttle Control	Wired control box
Nozzle	Gyratory Atomizing Nozzle
Nozzle Function	Wired remote
Nozzle Control	360 degree
Remote	Wired Joy Stick Control
Fuel Capacity	n/a
Battery	n/a
Trailer	n/a
Tires	n/a
Mounting	3 Point PTO
Overall Length w/ Nozzle	63 in
Height	24 in
Weight	275 lbs (125 kg)
Shipping Weight	370 lbs (168 kg)
Misting System	Gyratory Atomizing Nozzle
Hose Input	3/4 in utility / garden hose
Minimum Water Volume	1/3 gallon per minute
Maximum Water Volume	20 gallons per minute @120 psi
Minimum Water Pressure	40 psi
Maximum Water Pressure	120 psi
Droplet Size	50-200 micron
Throw Distance Horizontal	Up to 125 ft in neutral wind conditions
Throw Distance Vertical	Up to 50 ft in nuetral wind conditions
Machine Warranty	10 Year Manufacturer Warranty
Engine / Motor Warranty	n/a
Prop 65	WARNING: Cancer and Reproductive Harm - www.P65Warnings.ca.gov

Compare a Model

Spec

Monsoon PTO

Type

Three Point Hitch

Debris Type

Crop, Dust/Odor, Insect

Acreage

1 to 3, 10+, 4 to 6, 7 to 9

Input Power

Direct Drive Gearbox - 20 HP at PTO recommended

Start / Stop Control

Use Only at 540 RPM PTO Shaft Speed Max

Throttle Control

Wired control box

Nozzle

Gyratory Atomizing Nozzle

Nozzle Function

Wired remote

Nozzle Control

360 degree

Remote

Wired Joy Stick Control

Fuel Capacity

n/a

Battery

n/a

Trailer

n/a

Tires

n/a

Mounting

3 Point PTO

Overall Length w/ Nozzle

63 in

Height

24 in

Weight

275 lbs (125 kg)

Shipping Weight

370 lbs (168 kg)

Misting System

Gyratory Atomizing Nozzle

Hose Input

3/4 in utility / garden hose

Minimum Water Volume

1/3 gallon per minute

Maximum Water Volume

20 gallons per minute @120 psi

Minimum Water Pressure

40 psi

Maximum Water Pressure

120 psi

Droplet Size

50-200 micron

Throw Distance Horizontal

Up to 125 ft in neutral wind conditions

Throw Distance Vertical

Up to 50 ft in nuetral wind conditions

Machine Warranty

10 Year Manufacturer Warranty

Engine / Motor Warranty

n/a

Prop 65

WARNING: Cancer and Reproductive Harm - www.P65Warnings.ca.gov

Connect with a Sales Expert

Features

Gyratory Atomizing Nozzle.

Single, low maintenance non-plugging nozzle generates atomized water mist to control and suppress dust, odor and smoke particulates.

360 Degree Nozzle Rotation Without Airflow Reduction.

Corded Remote Control.

Momentary rocker switch joy stick with magnetic base connected via a 12ft. heavy duty cable.

360 Degree Nozzle Rotation Without Power Loss.

360 Degree Nozzle Rotation Provides Unlimited Spraying Angles.

Anti-Scalping Roller Protects Ground Surfaces.

The Anti-scalping roller protects ground surfaces when operating on uneven ground.
